And It Complements Our Other Commercial Stainless Steel HVAC Products
Cookie-cutter laminar flow diffusers don’t work for every operating room.
With that mindset, AJ Manufacturing developed a customizable ceiling solution that delivers both clean air and LED lighting to maximize ceiling space and retrofit existing critical environments.
The SSLORS is a customized air distribution system engineered to meet operating room standards. Its low-profile plenum with laminar flow diffusers and optional gel-seal HEPA filters meet air filtration requirements in your hospital’s OR.
How the SSLORS Lighted Ceiling System Works
Laminar flow diffusers from AJ Manufacturing utilize the concept of vertical air mass to produce a non-aspirating, low-velocity, uniform, downward piston of conditioned air, creating a protective barrier around the patient on the operating table and other key areas of the operating room. The air effectively blankets the surgical area to isolate the patient from contaminants.
Our modular air distribution system, the SSLORS, is available with or without a HEPA or ULPA filter and perimeter LED lights.
Our Lighted Air Diffuser is Modular
We designed the SSLORS for use in nearly unlimited layout options to meet project needs and regulatory requirements, including ASHRAE 170. Choose from an array of module sizes and configurations, with optional features like EC fans inside the plenum and IP67-rated built-in LED lighting.
Our lighted air diffuser system also can support booms, lighting, and other equipment via a strut channel.
If you need further customization, or if you want to talk to one of our experts about your options, contact us for more information.
Our Ceiling Air Diffuser with Lights Maximizes Space in the Operating Room
In part due to its modular nature and its low-profile common plenum, the SSLORS makes thoughtful use of ceiling space in operating rooms and other critical environments.
The optional built-in LED lights eliminate the need for traditional hanging lights and leave valuable ceiling real estate open for vital surgical equipment. A tidier look can also save time on cleaning and sanitization, as there are fewer fixtures to maintain.
Our Stainless Steel Air Diffuser Simplifies Installation
When you choose our air distribution system with integrated LEDs, you’re also simplifying the installation and electrical wiring processes.
Tunable and dimmable white LEDs light up your operating room, with the ever-important green LEDs on the same board. This combination reduces the number of drivers and amount of wiring necessary for installation. It also saves time throughout the process.
The SSLORS System Offers Better Lighting
Additional hanging light fixtures can interfere with the “wall of air” stream necessary to keep contaminants away from your patient and disinfected surgical tools.
With integrated LEDs on the SSLORS, lighting will never get in the way of that necessary air column that blankets the operating table. And because our LEDs are direct, efficient, and high-output, surgeon vision is never compromised by shadows or dim lighting.
Learn More About Key Features
The SSLORS lighted ceiling diffuser is especially engineered for hospital operating rooms. It’s made of Type 304 Stainless Steel with an antimicrobial white epoxy coat finish. It ships in large, factory-assembled sections.
Additional features include:
- Closed gasketed joints to ensure seal between each module>
- Adjustable equalization dampers on the room side>
- Easier installation with fewer hanging points and integrated earthquake hangar tabs>
- Removable faceplate with quarter-turn fasteners, for easy cleaning>
- Built-in, adjustable equalization damper with screwdriver slot adjustment>
- Perforated face with 3/32-inch diameter holes on 60-degree, 1/4-inch staggered centers>
- Rectangle duct inlets with 1” flange for duct connection>
- 13% free area>
Our Lighted Air Diffuser Undergoes Rigorous Testing
At AJ Manufacturing, we’ve perfected our fabrication process for all our commercial stainless steel HVAC products, including the SSLORS. This process includes leak testing.
Everything we produce is leak-tested in our custom-built HEPA unit leak test booth. It’s equipped with a photometer to ensure our products meet IEST standards for critical environments, like operating theaters.
Order the SSLORS Lighted Ceiling System and Other Commercial Stainless Steel HVAC Products from AJ Manufacturing
In the sheet metal business since the 1920s, AJ Manufacturing in Kansas City specializes in stainless steel HVAC components for critical environments and commercial buildings worldwide. Every piece is made to order and follows our time-tested fabrication process that ensures every product meets our exacting standards.
Find everything you need for your critical environment HVAC system at AJ Manufacturing. To learn more about our products, browse our website. If you’re ready to place your order, or if you’d like a customized estimate for your project, contact us online or via phone at (816) 231-5522.
